AKON’s A20-MX209 is a compact four channel tuner system that provides RF to IF conversion, pre-selection, and gain equalization. The modular design consists of 4 tuners, which each tuner handling 2 input bands from 0.5 - 18.0 GHz and 1 IF output at 1 GHz (single RF input from 0.5 - 18.0 also available) and features built-in LO1 amplification, filtering and multiplication using “high side” LOs. The unit also features an integrated DC-DC converter and LO presence and channel temperature monitoring.
| Model Number | A20-MX209 |
|---|---|
| Frequency Range (GHz) | 0.5-18.0 |
| Number of Input Channels | 2 (0.5 - 8.0, 8.0 - 18.0 GHz) |
| Input Impedence (Ohms) | 50 (nom) |
| RF Power Levels (dBm) | -75 to -10 |
| Recovery Time (µS) | 1 (max) |
| IF Output Channels | 4 |
| IF Center Frequency (GHz) | 1 |
| IF Bandwidth (MHz) | 500 +/- 250 @ 1 GHz Fc |
| Preselector Filter Rejection (dBc) | -60 +/- 15% Fc |
| IF Output Power (dBm) | +28 (max) |
| 1 dB Compression Point (dBm) | +21 (min) |
| Third Order Intercept (dBm) | +30 (min) |
| Output VSWR | 1.5:1 (max) |
| Channel to Channel Isolation (dB) | 60 (min) |
| Gain (dB) | +25 (nom) |
| Noise Figure (dB) | 10 (nom); 11 max (below 8 GHz) 11 (nom); 12 max (above 8 GHz) |
| Spurious Levels (dBc) | -60 (max) |
| Switching Time (nS) | 100 (max) |
| Power Supply(VDC) | +12 +/- 3% |
| Power Consumption (W) | 70 |
| Size (Inches) | 9.95 x 4.74 x 3.55 |
