AKON’s A60-ML006 is a medium-gain downconverter which accepts inputs in the 6.0 to 18.0 GHz band, incorporates a 3-channel preselector filter, each channel being 4 GHz wide, and individually down converts those channels to a 2.0 to 6.0 GHz IF output. Conversion gain is roughly 12 dB, and dynamic range is 48 dB. 0 dB SNR threshold is -68 dBm. Deselected channel isolation is over 60 dB and switching time is less than 200 ns typical.
| Model Number | A60-ML006 |
|---|---|
| Frequency Range (GHz) | 6.0 -18.0 |
| IF Output (GHz) | 2.0-6.0 |
| Noise Figure (dB) | 10 (max) |
| Switching Speed (nS) | 200 |
| Survival Power (W) | 2 (max) |
| SP2T Switch Isolation (dB) | 50 (min) |
| SP3T Switch Isolation (dB) | 30 (min) |
| SP2T Controls (TTL) | 2 bit |
| SP3T Controls (TTL) | 2 bit ganged |
| LO Input (dBm) | -10 (min) |
| VSWR | 2.5:1 (max) |
| LO Radiation (dBc) | -90 (max) |
| Aux RF Out Net Gain (dB) | 12 +/- 1 dB in 6.0 - 14.0 GHz; 12 +/- 2 dB in 14.0 - 18.0 GHz |
| IF OUT Frequency Bandwidth (GHz) | 2.0 - 6.0 |
| IF OUT Net Gain (dB) | 3 +/- 2 dB (6.0 - 14.0 GHz RF input) 3 +/- 3 dB (14.0 - 18.0 GHz RF input) |
| In Band Harmonics (dBc) | <-30 (max) |
| In Band Spurious (dBc) | <-30 (max) |
| IF Linear Dynamic Range (dB) | 48 (min) (-68 dBm to -20 dBm) |
| Power Supply(VDC) | +8.5, -8.5 |
| Power Consumption (W) | 8 (max) |
